Dual/Three Channel 4K+2K/4K+1080P+2K Dual Wifi Dash Cam
Product Parameters
|
Solution |
CPU |
Sigmastar SSC8868G |
|||
|
Video/Photography |
Video recording mode |
Three-channel/two-channel |
|||
|
Video resolution |
Dual-channel: 4K HDR 30FPS + 2K HDR 30FPS Three-channel: 4K HDR 30FPS + 1080P30FPS + 2K HDR 30FPS |
||||
|
Video Format |
Video Format |
H.264/H.265 MP4 |
|||
|
Image Format |
JPG |
||||
|
Audio Format |
AAC LC |
||||
|
Camera |
Photosensitive chip |
Front camera: SONY IMX678 8M sensor Interior camera: SONY IMX307 2M sensor Rear camera: SONY IMX675 5M sensor |
|||
|
Lenses |
Front lens: 3G4P+IR filter, Φ17mm, F1.75 Interior lens: 2G+4P+940 filter, Φ17mm, F1.55 Rear lens: 2G+4P+IR filter, Φ17mm, F1.55 |
||||
|
Viewing Angle |
forward |
Inside the car |
Behind the car |
||
|
D: |
135° |
136° |
139° |
||
|
H: |
115.2° |
115° |
106° |
||
|
V: |
64.6° |
61° |
77° |
||
|
Lens rotation angle |
Vertical rotation 85° |
||||
|
Number of cameras |
3 |
||||
|
Display |
Size |
3.16" IPS HD screen |
|||
|
Resolution |
820*320 |
||||
|
Type |
IPS |
||||
|
Touch |
Without touch |
||||
|
Wifi |
2.4G/5G |
RTL8821CS, 2.4/5G WIFI+BT |
|||
|
Bluetooth |
5.0/5.3 |
Support, share RTL8821CS |
|||
|
GPS |
Dual Mode |
Built-in, 18*18mm GPS module, 4mm ceramic antenna, 4pin interface |
|||
|
Memory |
CPU ROM (internal/external) |
2 external 128*16bit_2133 DDR3 96BGA (4G DDR3) |
|||
|
External Cache RAM |
SPI Nor flash 128M |
||||
|
Support external storage (TF card) |
8-256GB (card speed U1 and above) |
||||
|
Microphone |
Microphone |
4015 omnidirectional noise-cancelling microphone |
|||
|
Speaker |
Trumpet |
2014 8Ω 1W |
|||
|
Auxiliary light source |
LED night vision infrared light |
In-car camera with infrared light |
|||
|
LED fill light |
none |
||||
|
Product appearance |
Interface |
TYPE-C*2, TF card slot |
|||
|
Button |
Up/Down/Confirm/Menu/Power/RESET |
||||
|
Indicator Lights |
Power indicator light + working indicator light |
||||
|
Power supply |
Battery Type |
Supercapacitor |
|||
|
Battery capacity |
5.5V/3.5F |
||||
|
Maximum power consumption of this machine |
1.7A (5V three-way) |
||||
|
Power supply and charging equipment |
Input 12-24V, output 5V/2.5A, TYPE-C straight head, cable length 3.5M, no-load no higher than 5.5V, load 4.7-5.2V, anti-interference |
||||
|
High and low temperature |
Operating temperature |
-10℃--+60℃ |
|||
|
Storage temperature |
-20℃--+70℃ |
||||
|
USB Port |
Support functions(USB, PC camera) |
Support USB data transmission |
|||
|
Function |
Main features |
Loop Recording |
|||
|
Support 10-second pre-recording function for driving and parking monitoring collision |
|||||
|
Support 3-axis gravity sensing |
|||||
|
Support parking monitoring and time-lapse recording |
|||||
|
Support motion detection |
|||||
|
Supports automatic locking protection video when the vehicle is in collision |
|||||
|
WIFI, GPS support |
|||||
|
Support 3D noise reduction, image enhancement |
|||||
|
Support local dual-channel and three-channel |
|||||
|
Support 3 screens display at the same time |
|||||
|
Support 4K+1080P+2K three-way, local 4K+2K two-way |
|||||
|
TYPE-C power interface interoperability |
|||||
|
Supports front and rear SONY STARVIS 2 + in-car STARVIS |
|||||
|
language |
Existing languages |
English/French/Spanish/Germany/Italian/Russia/Japanese |
|||
|
Dimensions |
Bare metal size |
97*56.2*38.3mm |
|||
|
Weight |
Bare weight (including battery) |
To be determined |
|||
|
Standard accessories |
Standard accessories |
Car Charger |
|||
|
Bracket + Bracket 3M glue |
|||||
|
Static stickers |
|||||
|
manual |
|||||
|
CPL (optional) |
|||||
|
Sony IMX675 2K rear pull (R03D) |
|||||
|
Box Mark |
Packing size |
177.5*152.5*78mm |
|||
|
Quantity |
20pcs/box |
||||
|
Net weight |
13.6KG |
||||
|
Gross Weight |
14.6KG |
||||
|
Outer box size |
76.5×35.7×15.8CM |
||||
Mobile APP "Roadcam" for Android/ iOS
Exclusive New Custom Mold
This cutting-edge dashcam features a proprietary custom design, ensuring superior build quality and a distinctive aesthetic that sets it apart from generic models.
Built-In Button Battery for Time Backup
A permanent button battery preserves critical settings (e.g., date/time) even during power interruptions, ensuring uninterrupted recording and data accuracy.
Sleek, Hidden Installation
Designed with a minimalist, low-profile form factor, it blends discreetly into your vehicle's interior without obstructing visibility or aesthetics.
Innovative Thermal Management
The advanced cooling system and heat-resistant materials ensure reliable operation even in high-temperature environments, preventing overheating and performance drops.
High-Capacity Super Capacitor
Utilizing a super capacitor instead of traditional batteries, it offers explosion-proof safety, faster charge/discharge cycles, and longer lifespan in extreme conditions.
Sigmastar Industrial-Grade 5K Chip
Powered by the advanced Sigmastar 5K processor, this system delivers ultra-smooth 5K video encoding with industrial-level stability and performance, ideal for demanding environments.
Dual Sony Stavis Sensors (IMX678/IMX675)
Equipped with front and rear Sony Stavis sensors (IMX678 + IMX675), it captures crystal-clear footage with enhanced dynamic range and superior low-light sensitivity for unparalleled image quality.
Rear-Channel Hardware HDR + Starlight Night Vision
The rear camera features hardware HDR and Starlight Night Vision technology, ensuring sharp, balanced video even in extreme lighting conditions, with exceptional light capture for nighttime clarity.
5G High-Speed WiFi & Seamless Sharing
With 5G WiFi support, enjoy lightning-fast file transfers, real-time HD video previews, and effortless sharing via mobile apps-making remote access and management a breeze.
Built-In Dual-Mode GPS (Optional)
Integrated dual-mode GPS accurately records real-time driving routes and speed data, adding an extra layer of security and accountability for personal or fleet use.
